Milling, mixing, dispersion, and wet grinding technologies are vital in manufacturing across numerous industries.

Paints and coatings, printing inks, many food and drink products, cosmetic and personal care products, and pharmaceuticals are just some of the everyday consumer items that require the use of these machines in their production. Milling, mixing, and dispersion technologies are also used in the agriculture, construction, and renewable energy sectors.

The basket mill is one of the most widely used milling machines on the market today. Basket mills combine a milling chamber (the basket), grinding media (typically beads or balls), and pegs and screens as impact points in one machine. A mixing shaft rotates to circulate the slurry through the chamber and enable particle deagglomeration and size reduction.

Here at Hockmeyer, we refer to our basket mills as “immersion mills.” However, when we use these two terms, we are talking about the same technology. Other companies began using the term “basket mills” to differentiate their solutions from ours.

Since Hockmeyer started almost a century ago, milling technology has advanced dramatically. We are constantly seeking new ways to enhance efficiency, quality, and value for our clients. In this post, we will explore some of the advances in basket mill technology and how these have revolutionized manufacturing.

The Origins of Milling Technology

Humans have been milling for thousands of years. The earliest milling methods, such as stone grinding and pestle-and-mortar grinding, were laboriously performed by hand and primarily used for food production.

One of the most commonly used types of milling solution was the rotary quern, which utilized a pair of large stones to grind grain into flour. This was likely invented around the 1st Century BCE.

The Industrial Revolution brought astonishing advances and new technology for manufacturing, including the development of mechanical mixers.

Though a significant step forward from earlier hand grinding processes and techniques, these early machines were still relatively labor intensive. They also presented problems such as inefficiency and inconsistent particle sizes.

Modern technology has changed the game of milling, mixing, and dispersing equipment. By incorporating advanced materials, precision engineering techniques, and computerized control systems, manufacturers can now enjoy greater control and efficiency in dispersing and grinding processes.

The Emergence of Basket Mills

Hockmeyer invented the immersion mill, now commonly known as the basket mill, in the 1990s. Our working principle was to open the door to greater productivity and higher efficiency in particle reduction. Our basket mill design was granted a US patent in 1993.

Some of the earliest adopters of basket milling were the industrial paints and coatings, ink production, and chemicals sectors. Other industries soon followed, and basket milling is now regarded as one of the most efficient and effective ways of wet grinding: particle size reduction.

What Advantages Do Basket Mills Offer Over Horizontal Mills, Ball Mills, and Other Wet-Grinding Solutions?

Basket mills offer several compelling advantages over traditional milling techniques, such as horizontal and ball mills.

The basket volume of basket mills allows for more efficient processing of materials in each batch, enhancing productivity. Unlike other milling machines, basket mills have fewer parts and are, therefore, easier to set up, use, and clean.

Basket mills are versatile and can handle a wide range of raw materials. With customizable grinding fineness via interchangeable screens, narrow particle size distribution, superior speed controls, and easy submersible cleaning, they can adapt to many applications.

Key Technological Advancements in Basket Mill Design

Since creating the first immersion mill in the early 1990s, we have developed numerous technological advancements. We have adopted and utilized these technologies to refine, improve, and update our milling machines to meet the most exacting client needs in 21st-century manufacturing.

In this section, we will examine some of those technological advancements.

Improved Flow Mechanisms

Improved flow mechanisms have improved passage through the grind chamber, resulting in narrower particle size distribution for a higher quality final product.

We invented and patented three important flow-enhancing mechanisms for the basket mill:

Our HCP Immersion Mills feature a patented [2007] auger design on the upper part of the machine. This auger works with the patented [1996] bottom propeller to feed material through the milling basket chamber at optimal speeds and maximize material flow. The patented [2012] scraper/helical blade allows users to process high-viscosity materials while assisting with flow and controlling temperature. The bi-directional scrapers scrape the feedstock off the inside of the vessel, and the helical blade feeds the material back to the center of the tank to pass through the milling chamber.

Improved Efficiency….. 100%

Our counter-peg insert assembly [patent 1998] within the basket doubled the number of impact points and increased efficiency by 100%.

Automation and Process Control

Digital solutions allow for monitoring and data gathering during processing for well-informed fine-tuning decisions. Exact control over flow speed and temperature during the milling process affect the properties and qualities of the output, allowing manufacturers to create a more uniform and consistent product quality.

With built-in sensors and real-time monitoring, operator dependency and the risk of human error are reduced. These technologies allow for more rigorous monitoring and micro-adjustments, enhancing efficiency and reducing product waste.

Enhanced Temperature Control

Mixing, milling, and grinding machines are energy-intensive. Early iterations of these machines were prone to overheating, leading to equipment failures, long production times, and costly downtime.

However, the innovative cooling system of the basket mill prevents product overheating and keep machines running at optimal temperatures.

Integration with AI and Smart Technologies

Artificial intelligence (AI) has taken the world by storm and is making waves across numerous sectors, including the manufacturing industry. This technology allows manufacturers to monitor their machinery more efficiently and perform predictive maintenance and on-the-fly adjustments to keep it performing at its best for longer.

Similarly, integration with the Internet of Things (IoT) further enhances control systems, remote monitoring, and operation capabilities, allowing for better process control.

Modern Applications and Industry Impact

Basket mills are now utilized across various cutting-edge modern industries and applications, from the production of nanomaterials and advanced coatings to essential pharmaceuticals and more.

Absolute precision is of the utmost importance in these spaces. Modern basket mills can ensure this precision while also reducing production time and ensuring consistent and predictable product quality across batches.

Sustainability and the environment are also top priorities for today’s manufacturers. Modern basket mills offer various environmental benefits, including ease of cleaning, reduced waste, ergonomics, safety and energy conservation via improved productivity and efficiency.

Future Trends and Innovations in Basket Mill Technology

As we have seen, basket milling technology has advanced tremendously over the last three decades. However, the advances will not stop here.

At Hockmeyer, we are committed to continued innovation and utilizing the latest technologies to improve our clients’ milling, mixing, and dispersing processes.

Automation, AI, and the IoT will continue to play an essential role in optimizing milling processes as they become more sophisticated.

Similarly, the development of more sustainable and energy-efficient designs will be critical as the fight against climate change continues.

We expect to see more modular basket mills and hybrid milling solutions combining multiple technologies over the coming years, saving space and time by allowing more processes to be completed using one machine.

We also predict that basket mills will play a critical role in emerging industries such as biomedicine, electrified transit, the aerospace sector, and scientific research institutions in the materials science space.

Hockmeyer: The Leading Provider of Fast, Efficient Milling and Fine Grinding Solutions

Here at Hockmeyer, we have been on the cutting edge of milling and grinding technologies for decades. We patented the first immersion mill, now commonly known as a basket mill, and we are proud to continue innovating and playing a key role in industrial progress.

Our immersion basket mills offer an excellent grinding effect, superior particle size control, and ease of operation, all designed to shorten production times and enhance efficiency.

Our lab basket mill models allow prospective customers to try out our machines in a real-world setting to ensure they meet their needs before purchasing. To learn more about any of our products or services or to arrange to test a lab basket mill at our cutting-edge testing facility, please contact the team today.
